Dual-Module Intelligent Self-Cleaning Integrated System

Product Features:

  1. No disassembly required for cleaning
  2. One intelligent cleaning cabinet can support the cleaning of up to six integrated units
  3. Cleans the two main purification modules: the dynamic capture module and the electrostatic field module
  4. High level of automation, including automatic liquid filling, heating, pressurization, and spraying
  5. Extended cleaning cycles that help reduce the need for manual maintenance

This equipment is an intelligent maintenance solution specially developed for key oil fume purification units. By simulating professional manual cleaning steps—including heating, soaking, pressurization, and rinsing—it delivers thorough cleaning with no hard-to-reach areas left untreated. Its key advantage is maintenance without disassembly. After a one-touch cleaning cycle, the system requires only about 10 minutes of downtime before returning to operation, helping improve kitchen efficiency significantly.

Request A Quote
Technical Parameters Contact Us

Model

Size(m)L*W*H

Handling air volume m³/h

Voltage V

Power KW

DY-YZ-ZD-1.6

1600*1200*1200

4000

380

2.0

DY-YZ-ZD-1.8

1800*1200*1200

4000

380

2.0

DY-YZ-ZD-2.0

2000*1200*1200

5000

380

2.2

DY-YZ-ZD-2.2

2200*1200*1200

5000

380

2.4

DY-YZ-ZD-2.4

2400*1200*1200

6000

380

2.8

DY-YZ-ZD-2.6

2600*1200*1200

6000

380

3.2

Intelligent cleaning cabinet

562*423*1672

380
